TD133F TouchWo-13.3inch-Touch Screen all in one
Quantity
Product description
27mm 13.3 inch touch monitor/android pc
SKU:JD133
13.3 inch Fully enclosed touch displays, HDMl in, VGA. Android OS optionsKey Features:
- 27mm slim design 8-10.1-13.3-15.6 inch
- IP65 Fully enclosed
- Capacitive 10 points touch FHD 178/178 display
- Android 11 2G RAM+16G ROM/4G RAM+32G ROM
- USB HDMl LAN Audio WIFI BT
- The specifications can be viewed on Rescources below
Display
| Type | a-Si TFT-LCD WLED backlight; A Grade | ||
| Size | 13.3 Inch (16:9) | ||
| Display area | 294.3（W）*165.8（H）mm | ||
| Resolution | 1920*1080 | ||
| Brightness | greater than or equal to 250cd/m2 | Contrast | greater than or equal to 1000：1 |
| Response time | 25(Typ.)(Tr/Td) ms | Refresh rate | 60Hz |
| Number of colors | 16.7M < EDP 30 Pins > | ||
| Visual Angle H/V (°) | 85/85/85/85 (Typ.)(CR10) | ||
| Lifetime | 15000 hrs | ||
Touch Panel
| Touch Technology | Projected Capacitive | ||
| Response time | < 5ms | ||
| Touch Point | 10 points | ||
| Effective identification spacing | > 1.5mm | ||
| Scanning frequency | 200Hz | Scanning accuracy | 4096×4096 |
| Interface | USB 2.0,3.0 | ||
| Firmware | USB supported | Driver | Free drive |
| Operating current/voltage | 180Ma/DC+5V±5% | ||
| Surface hardness | 7H | ||
Power
| Input power | 110-240V AC 50/60Hz | Output power | DC 12V 3A |
| Monitor | ﹤20W | Speaker power | 8Ω1W |
| Android spec | ﹤25W | Standby power | ﹤0.5W |
Operation
| Operating | 0°C-50°C |
| Humidity Range (RH) | 10% - 80% |
| Storage temperature | -5°C-60°C |
| Storage humidity | 10% - 70% |
| Altitude | Below 5000m |
Configuration
| Available options | Touch Monitor | Android |
| CPU | External host required, refer to 3.1 for detailed parameters | RK3288/RK3568/RK3399/RK3368 |
| RAM | 2G/4G | |
| ROM | 8G - Default | |
| 16/32G Optiona | ||
| GPU | Android HD | |
| Resolution | 720P/1080P | |
| OS | Android 7.1/9.0/11 | |
| Network | Integrated 10/100 / 1000M adaptive network card, wireless network card 802.11a / b / g / n | |
Touch Monitor
| DC IN | 2.1mm DC12V*1 | Audio port | 1 |
| VGA input(15pin D-Sub) | 1 | HDMI input | 1 |
| USB- Touch control | 1 |
Android
| DC IN | 2.1mm DC12V*1 | Audio port | 1 |
| RJ45 | 1 | HDMI input | 1 |
| USB Input(OTG included) | 4 | Integrated WIFI | 1 |
| TF Slot | 1 | TTL/232/485 | 1 |
Accessary
| Manual&Warranty Card | *1 | ||
| Power Adapter | *1 | Wall mount Bracket/ Desktop Bracket | *1 |
| HDMI/USB cable | 1 pcs each（1.5 meters, match for touch monitor only） | ||
Dimension
| Screen | 13.3" |
| Display size | 294.3mm * 165.8 mm （16：9） |
| Machine size (W * H *T) | 325.8（W）×201.3（H）×27（T）mm |
| Package size (W * H *T) | 450（W）×283（H）×83（T）mm |
| VESA hole | 75×75 mm / 100×100 mm |
| Wall screw specifications | M4 |
| Net weight | 1.4 KG |
| G.W (packaging) | 2.75 KG |
