24VDC Input | 16 |
Relay Output | N/A |
Signal Indicator | Available |
Power Supply | 24VDC -15%/+20%, maximum of 3.2W. Provided internally in the main unit, no external input required |
Wiring Structure | Detachable terminal block |
Usage | Cannot work independently, must be used in conjunction with FL5/FC5 series main units |
Operating Temperature | -10~60°C |
Storage Temperature | -20~70°C |
Environmental Humidity | 5~95%RH (non-condensing) |
Installation | Directly installed on DIN 46277 rail (width 35mm) or fixed with screws |
Dimensions | 66mm×90mm×83mm |
